Attributes
- Panel Sizes (Single Sided, Double Sided)
- Panel Sizes (Multilayer)
- Panel Sizes (Flexible Circuits)
- Panel Sizes (Rigid-Flex)
- Maximum Layers
- Flex layer Counts
- Rigid Flex Layer Counts
- Maximum Board Thickness
- Minimum Core Dielectric Thickness
- Minimum Prepreg Dielectric Thickness
- Minimum Copper Weight – Inner Layer (oz)
- Minimum Starting Copper Weight – Outer Layer (oz)
- Maximum Copper Weight – Inner Layer (oz)
- Maximum Starting Copper Weight – Outer Layer (oz)
Standard
- 12″ X 18″, 18″ X 24″
- 12″ X 18″, 18″ X 24″
- 12″ X 18″, 18″ X 24″
- 12″ X 18″, 18″ X 24″
- 12
- 2
- 4
- .125″
- .003″
- .003″
- 1/2 oz
- 3/8 oz
- 6 oz
- 2 oz
Advanced
- 18″ X 24″
- 18″ X 24″
- 18″ X 30″
- 18″ X 24″
- 30
- 8
- 8
- .200″
- .002″
- .002″
- N/A
- 1/4 oz
- 8 oz
- 14 oz
Notes
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
Materials
- Isola 370HR
- Isola 185HR
- Isola FR406-FR406N
- Isola IS402
- Nan Ya FR-4-86
- Nan Ya NP-180R
- Nan Ya NP-180TL
- Ventec VT-42
- Ventec VT-47
- Ventec VT-481
- Ventec VT-5A2
- Ventec VT-4B Series
- Bergquist T-Clad
- Kingboard KB-6160
- Shengyi SN-L3
- Shengyi SN-L4
- Shengyi S1141
- Shengyi S1170
- Panasonic Megtron 6
- Panasonic R-F775
- Dupont Pyralux® FR Clads
- Rogers 3000 Series
- Rogers 4000 Series
- Rogers CITE
Standard
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
Advanced
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
IPC-4101
- /98/99/101/126
- /98/99/101/126
- /21/24/26
- /97/98/99/101
- /21
- *
- *
- /21
- /97/98/99/101
- /97/98/99/101
- *
- *
- *
- /21
- *
- *
- *
- *
- *
- *
- *
- *
- *
- *
Imaged Features
- Inner Layer Line Width
- Inner Layer Spacing
- External Layer Line Width
- External Layer Spacing
- Minimum Pad
- SMT Pitch
Standard
- 0.005″
- 0.005″
- 0.005″
- 0.005″
- 0.0015″
- 0.0010″
Advanced
- 0.003″
- 0.003″
- 0.003″
- 0.003″
- 0.008″
- 0.008″
Notes
- *
- Hoz. Copper
- *
- Hoz. Copper
- *
- *
Hole Technology
- Smallest Mechanical Drilled Via
- Aspect Ratio
- PTH Tolerance {+/-}
- NPTH Tolerance {+/-}
- Minimum Cu Clearance to Hole
Standard
- 0.0079″
- 10:1
- 0.003″
- 0.001″
- 0.008″
Advanced
- 0.006″
- 12:1
- 0.002″
- 0.001″
- 0.006″
Notes
- *
- *
- *
- *
- *
Solder Mask/Legend
- LPI Solder Mask
- Minimum Clearance
- Minimum Web
- Legend Color
Standard
- Green, Blue, Red, Clear
- 0.003″
- 0.005″
- White, Black
Advanced
- Black, White, LED White
- 0.002″
- 0.004″
- Yellow
Notes
- *
- *
- *
- *
Surface Finish
- Electroless Nickel Immersion Gold (ENIG)
- Electrolytic Nicked Gold (ENEG)
- Electroless Nickel Electroless Palladium Immersion Gold (ENEPIG)
- Immersion Silver
- Immersion Tin
- Hot Air Solder Level (HASL)
- Lead Free Hot Air Solder Level (LF HASL)
- Organic Solderability Preservatives (OSP)
Standard
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
Advanced
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
Notes
- *
- Verticle Gold Tab
- Outside Service
- *
- Outside Service
- *
- *
- Outside Service
Test
- Flying Probe Test
- TDR
- Ionics
- CMI XRF
Standard
- Yes
- Yes
- Yes
- Yes
Advanced
- Yes
- Yes
- Yes
- Yes
Notes
- *
- *
- *
- *
Additional Capabilities
- Buried/Blind Via
- Plugged Vias (mask)
- Castellated Holes
- Edge Plating
- Via Fill – Conductive/Non-Conductive
- Countersink/Counterbore/Beveling
- Milling/Controlled Depth
- Controlled Impedance
Standard
- No
- No
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes + / – 10%
Advanced
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes
- Yes + / – 5%
Notes
- *
- *
- *
- *
- *
- *
- *
- *
Our Capabilities
Comprehensive PCB Solutions for All Your Needs
Scanning PCB artwork
Photo tooling
Panelizing
Data Conversion.
FAQs
What customer asked to us !
We specialize in the production of single-sided and double-sided PCBs. Our advanced equipment and expertise allow us to deliver precise and durable PCBs tailored to your specific requirements.
We provide RoHS-compliant finishes, including immersion gold and lead-free HAL. These finishes ensure high-quality, environmentally friendly solutions for your PCBs.
Yes, we offer advanced scanning services for PCB artwork. Our technology ensures accurate reproduction, maintaining the highest standards of precision and detail.
Absolutely. We offer seamless data conversion services, ensuring your designs are compatible with our manufacturing processes, guaranteeing a smooth transition from design to production.
In addition to manufacturing single and double-sided PCBs, we offer photo tooling, panelizing, and a variety of other services to support your PCB production needs from start to finish.
